Polyworks Inspector

PolyWorks|Inspector™ is a universal 3D dimensional analysis and quality control software solution to control tool or part dimensions, diagnose and prevent manufacturing and assembly issues, guide assembly building through real-time measurements, and oversee the quality of assembled products by using portable metrology devices and CNC CMMs.

More info : https://www.innovmetric.com/en/products/polyworksinspectortm-packages

Loading...

Description

PACKAGES

Probing Probing++ Standard Premium
Single-point measuring device support for portable metrology • • • •
Single-point measuring device support for CNC CMMs • •
Point cloud digitizer support for portable metrology • •
Point cloud digitizer support for CNC CMMs •
Real-time quality meshing and offline point cloud meshing • •
PolyWorks|Modeler Light module •
PolyWorks|AR plug-in •
IGES/STEP neutral CAD file translator • • • •
Part alignment toolset • • • •
Dimensional control toolset • • • •
Smart GD&T toolset • • • •
Reporting toolset • • • •
Simulation mode for offline project setup • • • •
Repeatable multipiece measurement workflows • • • •
Statistical Process Control toolset (SPC) • • • •
One-year support/maintenance • • • •
AVAILABLE OPTIONS
Native CAD file translators Option Option Option Option
Airfoil gauges Option Option Option Option
More Info More Info More Info More Info

Technical Data

TECHNICAL SPECIFICATIONS

System Requirements

Minimum System Requirements*

  • CPU: Dual-core CPU
  • RAM: 4 GB
  • Graphics cards: Hardware-accelerated, professional OpenGL graphics card (NVIDIA certified cards and drivers) equipped with 1 GB of memory
  • Operating system: 64-bit Windows 7, 8.1 or 10, Professional Edition
  • Input device: Two-button mouse with wheel

*These requirements are adequate if you are planning to use single-point probing devices and your CAD model file sizes are smaller than 50 MB.

Recommended System Requirements*

  • CPU: Quad-core CPU
  • RAM: 32 GB
  • Graphics card: NVIDIA Quadro series graphics card equipped with 2 GB of memory (NVIDIA certified cards and drivers)
  • Operating system: 64-bit Windows 7, 8.1 or 10, Professional Edition
  • Input device: Two-button mouse with a wheel

*This configuration covers a broad range of applications by offering the performance required when importing larger CAD models or laser scanning large parts with high resolution. If you have doubts about the best system configuration for your type of application, contact our technical support team.
