| Stroke |
Arm axis |
1300mm |
| Base axis |
2120mm |
| Column axis |
2370mm |
| However, measurement is possible up to the stroke limit of a base plate in the case of using a semi-automatic measurement mode. |
| Accuracy in machine movement (at 20°) |
±0.08mm/axis for each axis |
| Motor drive control axis |
three axes, x, y and z |
| Axes to be simultaneously controlled |
5 axes in stationary state, and 3 axes simultaneously |
| Spindle power |
0.48 N·m |
| Spindle setting direction |
0 to 120° for A axis (15° step) |
| 0 to 180° for B axis (15° step) |
| Driving speed |
RAPID 0 to 10M/min. |
| JOG 0 to 1.2M/min. |
| Processing speed |
0 to 5M/min.(MaxF5000) |
| Input media |
CD-R or LAN |
| Electricity |
AC100V ±10% 50/60Hz |
